Extend Your Quantum System with a Reliable Connection

Connect and expand your Modicon Quantum racks with the Schneider Electric 140XCA71706 backplane expander cable. This essential 2-meter cable provides a robust link between system components using durable PROFIBUS connectors. The 140XCA71706 ensures reliable data and power transmission across your automation setup. It is built for the demanding conditions of industrial environments within the Modicon Quantum platform.

Core Cable Specifications & Physical Details

• Brand & Model: Schneider Electric Modicon Quantum 140XCA71706.
• Cable Type: Backplane Expander Cable for rack-to-rack connection.
• Length: Standard length of 2 meters (approx. 6.56 feet).
• Connectors: Features PROFIBUS-type connectors at both ends.
• Jacket Material: Durable PVC for flexibility and mechanical protection.
• Unit Weight: Approximately 1.00 lb (0.45 kg) for easy handling.

Environmental Ratings & Operating Limits

• Operating Temperature: Reliable performance from 0°C to 60°C.
• Operating Humidity: Up to 80% relative humidity (non-condensing).
• Storage Humidity: Up to 80% relative humidity (non-condensing).
• Operating Altitude: Suitable for use up to 1000 meters above sea level.
• Ingress Protection: Rated IP20 for basic protection against solid objects.

Compliance & Safety Information

• Key Certification: CE marked, conforming to European health and safety standards.
• Intended Use: Designed specifically for Schneider Electric Modicon Quantum systems.
• Application: Used to connect a primary CPU rack to a remote expansion rack.

Installation & Handling Guidelines

• Always power down the Modicon Quantum system before connecting or disconnecting the cable.
• Route the cable cleanly, avoiding sharp bends, pinch points, or high-traffic areas.
• Ensure the PROFIBUS connectors are fully seated and securely locked into the rack ports.
• Do not exceed the specified temperature, humidity, or altitude limits during operation.
• Verify the cable is not supporting its own weight at the connector joints to prevent strain.

Packaging & Shipping Info

• You will receive one Schneider Electric 140XCA71706 2-meter cable.
• The product ships in protective packaging to prevent damage during transit.
• We offer fast global shipping via reliable carriers: FedEx, UPS, and DHL.
• All orders are backed by a standard 12-month warranty.

Professional FAQs

• What is the primary function of this expander cable?

It extends the Quantum backplane, allowing you to add a secondary rack of I/O or specialty modules located away from the main CPU rack, thereby increasing system capacity.

• Can I daisy-chain multiple racks using this cable?

No, this is a point-to-point cable designed to connect one expansion rack directly to a master rack. For more complex topologies, you must consult the Quantum system architecture guide.

• Are the connectors keyed to prevent incorrect installation?

Yes, the PROFIBUS connectors have a specific orientation and locking mechanism. This design prevents accidental mis-mating and ensures a secure, correct connection every time.

• Is the 2-meter length sufficient for most panel layouts?

In our experience, the 2-meter length is ideal for connecting racks within the same control cabinet or between adjacent enclosures. For longer runs, you may need to reconsider rack placement.

• How does this cable differ from a standard communication cable?

This is a specialized backplane expander that carries both high-speed data and power for the remote rack's modules. A standard network cable only handles data communication.
