GE Fanuc IC697MDL640 125V DC 16-Point Discrete Input Module

The IC697MDL640 is a versatile 125V DC discrete input module from GE Fanuc's Series 90-70. This advanced module supports both positive and negative logic operations for flexible industrial control applications.

Technical Specifications

• Brand: GE Intelligent Platforms / GE Fanuc
• Series: Series 90-70
• Model: IC697MDL640
• Product Type: Discrete Input Module
• Logic Type: Positive/Negative
• Rated Voltage: 125 Volts DC
• Input Range: -35 to 145 V DC
• Number of Inputs: 16 points (4 isolated groups)
• Input Current: 5 mA at rated voltage
• Current Required: 0.3 A
• Power Type: DC Power
• LED Indicators: No

Installation & Configuration

• Configure the module using Windows-based or MS-DOS programming software.
• Connection options include SNP port or Ethernet TCP/IP port.
• Mechanical keys ensure only the correct module type can be installed.
• User-configurable settings eliminate the need for physical jumpers.

Packaging & Shipping

• We ship all orders promptly using reliable carriers like FedEx, UPS, and DHL.
• Your package contains one IC697MDL640 module ready for installation.

Frequently Asked Questions (FAQ)

• What voltage does this module operate at? It operates at 125V DC.
• How many input points does it have? It provides 16 discrete input points.
• Does it support both positive and negative logic? Yes, it supports both.
• Are there LED indicators for each point? No, this model doesn't include LEDs.
