Mitsubishi MR-J3-200B Servo Amplifier: High-Power 2kW Drive for Demanding Automation

Power your most demanding machines with the Mitsubishi MR-J3-200B. This 2000W servo amplifier delivers exceptional power and precision, featuring advanced control and easy setup for complex industrial applications.

Top Features & Benefits

• High Power Output: 2.0 kW rating drives large motors and high-inertia loads.
• Ultra-Precise Feedback: 18-bit absolute encoder (262,144 P/rev) for accurate positioning.
• Quick Setup: Auto-tuning feature enables fast commissioning and optimal performance.
• Smooth Operation: Advanced vibration suppression technology minimizes machine shake.
• Network Ready: Integrated SSCNET III/H high-speed fiber optic communication.

Complete Technical Specifications

Brand: Mitsubishi Electric

Series: MELSERVO-J3 Series

Model: MR-J3-200B

Rated Output Power: 2000 W (2.0 kW)

Rated Output Current: 11.0 A

Main Power Supply: 3-Phase, 200-230V AC, 50/60 Hz

Permissible Voltage Range: 170-253V AC

Control Circuit Voltage: 24V DC (±10%)

Control Method: Sine-wave PWM Control System

Communication Network: SSCNET III/H (Fiber Optic)

Encoder Resolution: 18-bit Absolute (262,144 pulses/revolution)

Key Technology: Advanced Vibration Suppression & Auto Tuning

Compatibility: Compatible with linear servo motors (e.g., 400N thrust rate)

Braking System: Built-in Dynamic Brake & Regenerative Resistor

Installation: Plug-and-play wiring system configuration

Operating Temperature: 0°C to +55°C

Storage Temperature: -20°C to +65°C

Vibration Resistance: Compliant with industrial standards

Weight: Approximately 2.27 kg (5.00 lbs)

Dimensions (Approx.): Compact modular design for panel mounting

FAQ – Professional Installation Guidance

What is the advantage of SSCNET III/H communication?

It provides ultra-fast, noise-resistant data transfer via fiber optics. This allows synchronized multi-axis control and longer cable runs without signal loss, perfect for complex machinery.

How does the 18-bit absolute encoder benefit my system?

It eliminates the need for a homing routine on power-up because it always knows the exact position. This saves cycle time and allows for immediate operation after a power loss.

Is the built-in regenerative resistor enough for a 2kW drive?

It handles standard braking energy. For high-duty cycles, rapid cycling, or very high inertia loads, you must calculate the regeneration power and likely add an external resistor bank.

Can I use this amplifier with a single-phase power source?

No. The MR-J3-200B requires a three-phase 200-230V AC power input for its main circuit. Ensure your facility has this power available.

The auto-tuning didn't fully eliminate vibration. What should I do?

First, ensure all mechanical parts (couplings, guides) are tight. Then, use the drive's manual tuning parameters to fine-tune the gain settings. Often, slightly reducing the speed gain can stabilize the system.

Package & Service Information

What's Included: 1 x Mitsubishi MR-J3-200B Servo Amplifier Drive Unit.

Quality Warranty: Protected by a comprehensive 12-month warranty.

Shipping Options: Delivered safely worldwide via FedEx, UPS, or DHL express services.
