SICK S30A-6011CA S3000 Advanced Safety Laser Scanner
Enhance your machine safety with the SICK S30A-6011CA. This advanced laser scanner provides reliable area protection. It creates safe zones around hazardous machinery. Quickly stop equipment when a person enters the danger area. Perfect for automated systems and robotic cells.
- Extended Protection: Offers up to 8 meters of measuring range for flexible safeguarding.
- Fast Response: Reacts within 60 ms to ensure immediate machine stoppage.
- Wide Coverage: Scans a broad 190-degree area for comprehensive monitoring.
- Robust Build: Features an IP65-rated aluminum housing for durable industrial use.
Product Overview
The SICK S30A-6011CA is part of the S3000 Advanced series. This safety laser scanner is designed for modern industrial safety applications. It uses laser technology to monitor access to dangerous machine areas. With its configurable fields, it adapts to various production layouts. It is an essential component for achieving safety compliance.
Detailed Technical Specifications
Brand & Model: SICK S30A-6011CA
Series: S3000 Advanced Series
Type: Safety Laser Scanner
Measuring / Protective Field Range: Up to 8 meters
Warning Field Range: Up to 49 meters
Scanning Angle: 190°
Resolution: Configurable, from 30mm to 150mm (Min. 14mm)
Response Time: ≤ 60 ms
Supply Voltage: 24V DC (Range: 16.8V - 28.8V DC)
Connection: Male Connector, M12, 5-pin
Outputs: 2 PNP safety outputs (OSSDs), short-circuit protected
Simultaneous Fields: Up to 4 fields monitored at once
Enclosure Rating: IP65
Housing Material: Aluminum die-cast
Operating Temperature: Standard industrial range
Weight: 3.3 kg
Other ID: 1023547, 4079255
Key Features & Benefits
High Flexibility: Program multiple protective and warning fields to match your layout.
Reliable Safety: Meets international standards for machine safety (e.g., SIL, PL).
Easy Integration: Standard 24V DC power and M12 connector simplify wiring.
Contour Teaching: Can learn and reference existing structures for easier setup.
Diagnostic Capabilities: Provides outputs for system status and troubleshooting.
Frequently Asked Questions (FAQ)
What is the main difference between the Advanced and Professional series?
The Advanced series, like this model, offers excellent performance for most applications. The Professional series often has more advanced software features and field configuration options.
How far away can it detect a person?
It can reliably detect a person within its configured protective field, which can be set up to 5.5 meters. For warning purposes, it can see objects up to 49 meters away.
Can it be used outdoors?
Its IP65 rating protects against dust and water jets, but it is primarily designed for indoor industrial use. For full outdoor use, specific environmental factors must be considered.
What cables are needed to connect it?
It has a built-in male M12 5-pin connector. You will need a matching female M12 cable to connect it to your control system's power and inputs.
Is programming difficult?
No. You use SICK's free SOPAS ET software on a PC to configure the protective fields graphically. The process is visual and intuitive.
Shipping & Warranty Details
Package Contents: One SICK S30A-6011CA Safety Laser Scanner.
Shipping Methods: We ship worldwide using FedEx, UPS, and DHL for reliable delivery.
Warranty Coverage: This product comes with a 12-month warranty for your assurance.
