Complete Bently Nevada Proximity Probe Housing Kit
New original Bently Nevada 21000-34-10-20-095-04-02 assembly. Ready for industrial monitoring. This kit has a long 9.5 inch probe penetration. It comes in sealed factory packing. Your purchase includes our trusted 12-month warranty.
Key Product Details
- Brand: Bently Nevada
- Main Model: 21000 Series Housing Assembly
- Your Exact Part: 21000-34-10-20-095-04-02
- Construction: Aluminum body with 304 stainless steel sleeve
- Probe Type: 3300 XL 8mm with connector protector
- Cable Length: 1.0 meter (39 inches) included
- Total Max Length (C+D): 32.9 inches (83.5 cm)
- Weight: About 1.1 kg (2.4 lb) without fittings
Part Number Configuration Explained
Every suffix in 21000-34-10-20-095-04-02 has a meaning.
- Suffix 34: 8mm probe for hazardous areas. Includes connector protector.
- Suffix 10: Provides a 1.0 meter long probe cable.
- Suffix 20: Kit contains a 2.0 inch standoff adapter.
- Suffix 095: Allows for deep 9.5 inch probe penetration.
- Suffix 04: Includes one 3/4-14 NPT plug only.
- Suffix 02: Mounting thread is standard 3/4-14 NPT.
Technical Specifications
- Maximum Extension with Visible Probe: 17.0 in (43.18 cm)
- Enclosure Certification: CSA Type 4, Explosion Proof
- Industry Standard: Fully compliant with API 670
- Application Suitability: For intrinsically safe systems in hazardous areas
- Mounting: Designed for external mounting on machinery
- Sealing: Includes O-rings and thread seal for protection
Package Contents
- One complete housing assembly (body, dome cover, sleeve)
- One reverse mount 8mm proximity probe
- One 1.0 meter probe cable
- O-rings and thread sealant
- 2.0 inch standoff adapter
- One 3/4-14 NPT plug
- All factory documentation
Shipping & Support
We ship globally with reliable carriers like FedEx, UPS, and DHL. Every Bently Nevada 21000-34-10-20-095-04-02 kit is covered by a 12-month warranty for quality assurance. Our team offers full technical support.
Expert FAQ
What is the "Maximum (C)+(D) Dimension" of 32.9 inches?
This is the total possible extended length of the housing and probe. It helps you check for clearance during installation planning.
Does suffix "04" for fittings include cable seals?
No. Option "04" includes only one NPT plug. Choose a different suffix if you need cable seals or reducers.
Is this housing explosion-proof?
Yes. When ordered with specific probe options, it carries CSA explosion-proof ratings for hazardous area use.
What is the benefit of the 9.5 inch probe penetration?
Deep penetration allows the probe to reach the measurement point on large machinery or through thick mounting structures.
Can I use my own conduit fittings with this housing?
Yes. The housing has standard 3/4-14 NPT ports. You can use compatible industrial fittings from other brands if needed.
