Bently Nevada 21000-34-10-15-095-04-02 | 8mm Sensor Probe
UBEST – Fornitore Globale Affidabile di Parti per Automazione
Offriamo un'ampia gamma di pezzi di ricambio per automazione industriale disponibili in magazzino. Tutti i prodotti sono coperti da una garanzia di 12 mesi e da un rimborso di 30 giorni per problemi di qualità.
Brand New Bently Nevada 21000 Probe Housing Kit
Get a new and original Bently Nevada 21000-34-10-15-095-04-02 assembly. It is perfect for hazardous area machine monitoring. The kit comes sealed in factory packing. It ensures reliable vibration and position measurement.
Key Product Specifications
- Brand & Model: Bently Nevada 21000-34-10-15-095-04-02
- Probe Type: 8mm 3300 XL with protected connector
- Cable Spec: 1.0 meter long (39 inches)
- Standoff Adapter: 1.5 inches included
- Probe Reach: Penetration depth of 9.5 inches
- Fitting: One 3/4-14 NPT plug
- Mounting: 3/4-14 NPT thread
- Housing Build: Aluminum with 304 stainless steel sleeve
- Max Assembly Length: 32.9 inches (83.5 cm)
- Approx. Weight: 1.1 kg (2.4 lbs) without fittings
Understanding Your Part Number
The code 21000-34-10-15-095-04-02 tells you exactly what's inside.
- 21000: The main housing assembly model.
- 34: Has an 8mm probe for hazardous areas.
- 10: Uses a 1.0 meter sensor cable.
- 15: Includes a 1.5 inch standoff adapter.
- 095: Probe extends 9.5 inches into the housing.
- 04: Comes with one 3/4-14 NPT plug.
- 02: Housing has 3/4-14 NPT mounting threads.
Package Contents
- One aluminum housing with stainless sleeve.
- One reverse-mount 8mm proximity probe.
- One 1.5 inch standoff adapter.
- Dome cover, probe sleeve, and O-rings.
- Thread seal and one 3/4-14 NPT plug.
Important Features & Support
- Hazardous Area Rated: Designed for explosion-proof locations.
- Industry Standard: Meets API 670 for external mounting.
- Durable Enclosure: Certified as a CSA Type 4 housing.
- Full Warranty: Backed by a 12-month warranty for peace of mind.
- Global Shipping: We deliver quickly via FedEx, UPS, and DHL.
Professional FAQs
What is the purpose of the 1.5 inch standoff adapter?
The standoff adapter creates space between the housing and mounting surface. This allows for easier installation and cable routing in tight spaces.
Can I use this housing without the standoff adapter?
Yes. The standoff adapter is optional. You can mount the housing directly if your application does not require the extra spacing.
What does a 9.5 inch probe penetration allow me to measure?
This long penetration is for measuring large machinery. It is ideal for applications where the sensor must reach deep into a bearing housing or casing.
Is the included NPT plug sealed?
You need to apply thread sealant separately. The plug itself does not come pre-sealed for maximum installation flexibility.
How does this housing help with intrinsic safety?
The housing provides an explosion-proof enclosure. It contains any potential spark from the probe circuit. This protects volatile surrounding atmospheres.
