Flexem FE7370WE-4G: Your All-in-One Industrial HMI Solution

This 7-inch HMI packs power and connectivity. It has a bright screen, a dual-core processor, and built-in 4G IoT. Perfect for many factory and machine applications. No extra modules needed for remote access.

Why Choose The FE7370WE-4G?

• Ready for IoT: Built-in 4G module connects your machine anywhere.
• Crystal Clear Display: High-brightness 350 nit screen for easy viewing.
• Wide Compatibility: Talks to over 100 different machine and PLC brands.
• Strong & Durable: IP65 front panel protects against dust and water.
• Easy to Use: Simple setup with USB, Ethernet, or SD card.

Complete Product Specifications

Brand & Model: Flexem FE7370WE-4G

Display: 7" TFT LCD | 1024 x 600 Pixels | 24-bit Color | 350 cd/m² Brightness

Processor: Dual-core Cortex-A7 @ 1.0 GHz

Memory: 4 GB Storage (eMMC) | 256 MB RAM (DDR3)

Connectivity:

Ethernet: 1 x 10/100 Mbps Port

USB: 1 x Type-A, 1 x Type-C OTG

Serial Ports: COM1 (RS232/485/422), COM2 (RS485), COM3 (RS232)

Wireless & Expansion:

4G LTE: Built-in (Bands: FDD B1/B3/B5/B8; TDD B38/B39/B40/B41)

SD Card Slot: Available

Bluetooth: Available

Data Capacity:

Real-time Monitoring: 300 Data Points

Alarms: 100 Notifications

Data Logging: 30 History Trends

Edge Computing: 20 Scriptable Points

Power: DC 24V (9V-28V Range) | Under 10 Watts | Surge Protected

Environmental:

Operating Temp: 0°C to +50°C

Storage Temp: -20°C to +60°C

Humidity: 10% to 90% (Non-condensing)

Physical:

Front Protection: IP65 (NEMA 4X)

Material: Engineering Plastic

Panel Cutout: 190 mm x 136 mm

Unit Size: 204 mm x 145 mm x 34 mm

Weight: Approx. 472 grams

Frequently Asked Questions (FAQ)

Q: Does the FE7370WE-4G need an extra box for internet connection?

A: No, it does not. The 4G cellular modem is already inside the HMI. Just insert a SIM card and configure it to connect your machine to the network.

Q: Can I use this HMI with my old PLC?

A: Most likely, yes. It supports a huge library of over 100 industrial protocols, including common ones like Modbus, Siemens S7, Allen-Bradley, and Mitsubishi.

Q: How do I get the program onto the HMI?

A> You have three easy options: copy the project file to a USB flash drive, connect directly with a USB cable, or download it over your local Ethernet network.

Q: What happens if the power flickers briefly?

A: The FE7370WE-4G is built to handle short power interruptions. It can tolerate power dips of less than 5 milliseconds without shutting down or losing data.

Q: Can I write custom logic on this HMI?

A: Yes. It includes edge computing features with script programming support for up to 20 points. This allows you to add simple logic or calculations right at the machine level.

What's In The Box?

1 x Flexem FE7370WE-4G HMI Unit

1 x Power Cable

1 x Set of Mounting Clips

1 x Quick Installation Guide
