GE Fanuc IC200NAL110 Nano PLC | 6 Inputs 4 Relay Outputs Versamax
UBEST – Fornitore Globale Affidabile di Parti per Automazione
Offriamo un'ampia gamma di pezzi di ricambio per automazione industriale disponibili in magazzino. Tutti i prodotti sono coperti da una garanzia di 12 mesi e da un rimborso di 30 giorni per problemi di qualità.
GE Fanuc IC200NAL110: Versamax Nano Programmable Logic Controller
Discover the compact power of the IC200NAL110 Nano PLC. This GE Fanuc Versamax controller packs 6 inputs and 4 outputs into a small 1-pound unit. Perfect for basic automation tasks, it offers flexible control for various applications.
Technical Specifications
- Brand: GE Fanuc
- Series: Versamax
- Model: IC200NAL110
- Type: Nano Programmable Logic Controller
- Input Points: 6 DC inputs
- Output Points: 4 relay outputs
- Output Rating: 2A per relay
- Output Type: SPST (Single Pole Single Throw)
- Voltage Range: 5-250VAC / 30VDC
- Input Voltage: 12VDC operating
- Input Impedance: 1.3 kiloohms
- Resolution: 8-bit
- Hold-up Time: 3 milliseconds
- Counter Frequency: 10 kHz
- Weight: 1 pound
Simple Installation
The IC200NAL110 controller installs easily in any control panel. Its compact design fits in tight spaces. The open enclosure design provides excellent heat dissipation.
Application Flexibility
This IC200NAL110 Nano PLC works with various sensors and output devices. The relay outputs can control lights, small motors, solenoids, and other industrial devices.
Warranty & Support
We provide a 12-month warranty on this product. Our technical team offers programming and installation support.
Global Shipping
We ship worldwide using FedEx, UPS, and DHL. All orders include full tracking and insurance coverage.
Frequently Asked Questions
Q1: What types of loads can the relay outputs control?
A1: The relays can handle both AC (up to 250V) and DC (up to 30V) loads at 2A per output.
Q2: Can the inputs be used for high-speed counting?
A2: Yes, the DC inputs can function as standard inputs or high-speed counters up to 10kHz.
Q3: What programming software works with this controller?
A3: The controller uses standard Versamax programming software for easy configuration.
Q4: Is this controller suitable for outdoor use?
A4: No, the open enclosure design is not rated for water resistance or outdoor environments.
Q5: What is the maximum input voltage for the DC inputs?
A5: The DC inputs operate with 12VDC signals and have 1.3 kiloohms impedance.
