GE Mark VI Turbine Protection Board IS215VPROH2BC
- Premium Quality & Ready to Ship
- Complete 12-Month Protection
- Fast Global Express Delivery
- Full Testing Before Dispatch
Product Overview
The IS215VPROH2BC is a Turbine Protection Board made by General Electric for Mark VI systems. This critical IS215VPROH2BC board provides emergency trip and overspeed protection for turbines.
Technical Specifications
Brand: General Electric
Model: IS215VPROH2BC
Series: Mark VI
Product Type: Turbine Protection Board
Frame Rate: Up to 100 Hz
Power Supply: 125 VDC
Operating Temperature: 0°C to 60°C
MPU Input Range: 2 Hz to 20 kHz
MPU Sensitivity: 27 mV minimum at 2 Hz
Solenoid Response: 0.1 second time constant
Trip Solenoids: 6 per VPRO board
Redundancy: Triple Modular Redundant (TMR)
On-board Voltages: 5V DC and 28V DC
Fuse Rating: 15A maximum
Country of Origin: USA
Power System
125 VDC input from PDM
On-board 5V DC generation
On-board 28V DC generation
Three independent power supplies
Redundant power architecture
Compatibility
Works with TPRO terminal boards
Compatible with TREG boards
Mark VI control systems
Gas, steam, and wind turbines
Simplex and TMR configurations
Warranty & Shipping
All products include 12-month comprehensive warranty. International shipping via FedEx, UPS, and DHL. Same-day dispatch available.
Professional FAQ
How many trip solenoids can the board control?
The board can control up to six trip solenoids, with three managed by each TREG terminal board.
What redundancy level does the board support?
It supports Triple Modular Redundancy with three independent X, Y, Z protection sections.
Can the board operate during turbine runtime maintenance?
Yes, one protection section can be shut down for maintenance while the turbine continues running.
What communication interfaces are available?
The board features Ethernet IONet for communication with control modules and terminal boards.
What types of turbines is this board designed for?
It protects gas turbines, steam turbines, and wind turbines in various industrial applications.
