Woodward 8440-2057 Genset Controller: Multi-Unit Power Management
The 8440-2057 controller delivers advanced control for single or multiple generator systems. This back-mount unit supports up to 32 gensets with comprehensive protection features.
- Fast Worldwide Shipping - FedEx, UPS, DHL Express
- Reliable Performance - 12-month quality warranty
- Multi-Unit Control - Manages up to 32 generators
- Easy Configuration - PC software setup and monitoring
Technical Specifications
Brand & Model: Woodward 8440-2057 (easYgen-3100-1 P2)
Mounting Type: Back panel cabinet installation
Housing Material: Metal enclosure for durability
Dimensions: 282mm W x 216mm H x 96mm D
Operating Temperature: -20°C to +70°C
Power Consumption: < 0.15W per path
Frequency Range: 40-85 Hz (50/60 Hz standard)
Resolution: 11-bit measurement precision
CT Inputs: 1A current transformer inputs
Alarm Outputs: 12 total (10 configurable)
PID Controllers: 3 fully configurable units
Engine Support: Gas and diesel engines
Communication: CANopen for external I/O
Max Systems: Controls up to 32 generator units
Key Features
Multi-Genset Management - Coordinates up to 32 units in parallel
Engine Temperature Protection - Cylinder temperature monitoring
Flexible PID Control - Three configurable PID controllers
Dual Fuel Support - Works with both gas and diesel engines
Remote Configuration - PC software setup via ToolKit
Frequently Asked Questions
How many generators can the 8440-2057 control?
It can manage up to 32 generator units in parallel operation.
Does this controller have a built-in display?
No, it's designed for back-panel mounting and controlled via PC software.
What types of engines does it support?
It works with both gas and diesel engines with customized start/stop logic.
How many alarm outputs are available?
There are 12 alarm outputs, with 10 that can be customized for specific alerts.
What software is needed for configuration?
Woodward ToolKit software is used for setup and monitoring.
Warranty & Shipping
All 8440-2057 controllers come with 12-month warranty coverage. We ship internationally using FedEx, UPS, and DHL services.
