GE Fanuc IC697MDL651 5V DC Input Module - Series 90-70 PLC

W magazynie
Manufacturer:
GE
Product No.:
IC697MDL651
Condition:
In Stock
Product Type:
DC Input Module
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Zaufany Globalny Dostawca Części do Automatyki

Oferujemy szeroki wybór dostępnych od ręki części zamiennych do automatyki przemysłowej. Wszystkie produkty objęte są 12-miesięczną gwarancją oraz 30-dniowym zwrotem w przypadku problemów z jakością.

O nas | Kontakt

GE Fanuc IC697MDL651 5V DC 32-Point Input Module

Product Summary

The GE Fanuc IC697MDL651 is a 5V DC input module for Series 90-70 PLCs. It offers 32 high-density TTL inputs. Perfect for fast, digital signal control. It includes LED status lights and noise filtering.

Key Benefits

32 input points. Low 5V DC power. Two filter options (1ms or 10ms). Long cable support (30 meters). Easy software setup. Built-in pull-up resistors.

Technical Details

  • Brand: GE Fanuc
  • Series: Series 90-70
  • Model: IC697MDL651
  • Module Type: DC Input Module
  • Input Points: 32
  • Rated Voltage: 5 V DC
  • Voltage Range: -3 to +7 V DC
  • ON-State Voltage: -3 to 0.5 V DC
  • OFF-State Voltage: 2 to 7 V DC
  • ON-State Current: 1.7 mA (Typical)
  • OFF-State Current: 1.1 mA (Max)
  • Input Impedance: 5.9 kΩ ±5%
  • Current Required: 0.53 A
  • Isolation Voltage: 1500 V
  • Cable Length: 30 m (98.4 ft) max
  • Filter: 1 ms or 10 ms selectable

Package Contents

One (1) GE Fanuc IC697MDL651 input module. Installation guide.

Simple Installation

Snap into a Series 90-70 rack. Connect your sensors and devices. Configure filter settings in software. The LEDs show real-time input status.

Ideal For

This IC697MDL651 module works with TTL-level devices. Use it with digital sensors, switches, and encoders.

FAQ

  • What is the input impedance?
    The input impedance is 5.9 kΩ with a ±5% tolerance.
  • How do I select the filter time?
    The filter time (1ms or 10ms) is selected through the PLC configuration software.
  • What does the isolation voltage mean?
    The 1500V isolation protects the PLC from voltage spikes on the input lines.
  • Can I use long cables with this module?
    Yes, the module supports cables up to 30 meters (98.4 feet) in length.
  • Is external power needed for the inputs?
    No, the module includes built-in pull-up resistors, so no external power is required for the inputs.
  • Shipping & Warranty

Shipped globally via FedEx, UPS, and DHL. Backed by a 12-month warranty for peace of mind.
