MICS3-ABAZ55IZ1P01 SICK microScan3 Core Safety Scanner

W magazynie
Manufacturer:
SICK
Product No.:
MICS3-ABAZ55IZ1P01
Condition:
In Stock
Product Type:
Safety Laser Scanner
Product Origin:
DE
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Zaufany Globalny Dostawca Części do Automatyki

Oferujemy szeroki wybór dostępnych od ręki części zamiennych do automatyki przemysłowej. Wszystkie produkty objęte są 12-miesięczną gwarancją oraz 30-dniowym zwrotem w przypadku problemów z jakością.

O nas | Kontakt

SICK MICS3-ABAZ55IZ1P01 microScan3 Core Safety Laser Scanner

Protect complex areas with flexible, intelligent sensing. The SICK MICS3-ABAZ55IZ1P01 is a Type 3 safety laser scanner from the microScan3 Core series with integrated EtherNet/IP CIP Safety connectivity. It creates protective fields up to 5.5 meters and monitors up to 8 different fields simultaneously. Perfect for safeguarding hazardous zones around AGVs and machinery with its wide 275° scanning angle.

Key Features & Benefits

  • Flexible Field Configuration: Monitor up to 8 fields (protective, warning, contour) and 4 simultaneously for complex layouts.
  • Direct Network Safety: Integrated EtherNet/IP CIP Safety provides 4 safe outputs via network, simplifying wiring.
  • Wide Area Coverage: Large 275° scanning angle and 5.5m protective range for comprehensive coverage.
  • Easy Configuration: Use SICK Safety Designer software for intuitive setup via USB or Ethernet.
  • Robust Industrial Design: IP65 housing, aluminum construction, and operates from -10°C to +50°C.

Complete Technical Specifications

Brand SICK
Series microScan3 Core
Full Model Number MICS3-ABAZ55IZ1P01
Product Version microScan3 Core - EtherNet/IP
Device Type Type 3 Safety Laser Scanner
Safety Rating PL d, CAT 3, SIL 2, IEC 61496 Type 3
Protective Field Range 5.5 m
Warning Field Range Up to 40 m
Scanning Angle 275°
Configurable Resolution 30, 40, 50, 70, 150, 200 mm
Safety Interface EtherNet/IP with CIP Safety (4 safe outputs)
Supply Voltage 24 V DC (16.8 - 30 V)
Connection M12 Connectors (Power & Network)
Enclosure Rating IP65
Operating Temperature -10°C to +50°C

Installation & Configuration Guide

Mount the scanner securely at the recommended height and angle. Connect the 24V DC power to the M12, 4-pin A-coded connector. Connect the two M12, 4-pin D-coded ports to your EtherNet/IP network. Configure protective fields, warning zones, and monitoring cases using the SICK Safety Designer software on a PC (via USB or Ethernet). The integrated display helps during setup and diagnostics.

System Compatibility & Integration

This scanner communicates directly via EtherNet/IP with CIP Safety protocol, allowing seamless integration into compatible safety controllers and PLCs from Allen-Bradley and other vendors supporting CIP Safety. It supports Device Level Ring (DLR) topology for network redundancy.

Package Contents

  • One (1) SICK MICS3-ABAZ55IZ1P01 Safety Laser Scanner with pre-mounted system plug.
